Solis String Inverters

Solis Mini (1-3.6)K

Single-phase string inverter

The single-phase Solis Mini 1-3.6 kW string inverters are the ideal solution for small residential installations.

Small in size and easy to install, the Solis Mini come with a DC disconnect switch and have a wide range of input voltages to allow you to collect the maximum amount of energy possible from the photovoltaic system with a maximum efficiency up to 97.5%.

Main features:

Easy Installation

IP65

10 year guarantee

“Zero entry” function (with accessory)

WiFi Monitoring included

Efficiency up to 97,5%

Solis Single-phase (2.5-6)K

Single-phase string inverter

Solis single-phase 2.5-6 kW string inverters with double MPPT and DC disconnect switch represent an optimal solution for residential installations.

These inverters have a wide range of input voltages to allow you to collect the maximum amount of energy possible from the photovoltaic system.

Main features:

Easy Installation

IP65

10 year guarantee

“Zero entry” function (with accessory)

CEI-021

Efficiency up to 98,1%

Solis Three-phase (6-20)K

Three-phase string inverter

Solis three-phase 6-20 kW string inverters (4th generation) with double MPPT and DC disconnect switch represent the optimal solution for residential, commercial and small industrial systems.

Solis three-phase inverters already work at low input voltage ranges, with an activation threshold of 180V.

This type of inverter can be parallelized with three-phase hybrid inverters.

Main features:

IP65

CEI-021

Possibility of “zero grid entry” function

Efficiency up to 98,7%

Solis Three-phase (50-60)K

Three-phase string inverter

Three-phase String Inverters with 50 and 60 kW of power.

Equipped with 5/6 independent MPPTs with fast and accurate MPPT algorithm, it has been designed without fuses to avoid the risk of fire.

With type II surge protectors for DC / AC, it is also equipped with a DC polarity reversal alarm.

Main features:

“Zero entry” function (with accessory)

CEI-021

IP66

Efficiency up to 98,8%

Solis Three-phase (80-110)K

Three-phase string inverter

Three-phase String Inverter with power of 80 kW, 100 kW and 110 kW is equipped with 9/10 independent MPPT and compatible with double-sided modules.

Remote firmware update is possible.

Main features:

CEI-021

Efficiency up to 98,7%

IP66

PC010-Rev.004-ENG-Solis-String-Inverters.pdf
